Explosionproof

TS-SG EX10

Features

Aluminium alloy die-cast body, Vandal resistant and tamper-resistant
Full keypad with memory, 10 button programmable speed-dial telephone, Illuminated button
Explosion-proof grade: ExD ib Zone-1 & Zone-2, IIA,IIB
The phone has good stability and strong anti-interference ability, in line with the national standard GB/T 15279-94
Zinc-aluminum alloy die-casting shell, sturdy and durable, good airtightness, and strong corrosion resistance
Built in 25watt RMS Power amplifier for external speaker
LAN /POEE line powered. TCP /IP SIP Supported
Lightening protection to ITU-T K.21
Noise cancelling microphone
Hearing Aid compatible receiver
Selectable 7-minute time out optional

Key Features	Description
Explosionproof Protection	Zone-1 & Zone-2, IIA, IIB
Types of Weatherproof Protection	Weatherproof IP67
MTBF	1,00,000 Hour
Keypad	Heavy Duty SS 316L Keypad 12+3 Extra Keys Hot Key Configuration
Call Controlling Signalling	VOIP SIP Info (DTMF), RFC 2833 (DTMF
Power Supply	24 VDC
IP Protocols	IPv4, UDP, DHCP, SIP
Network	10/100 Base TX Ethernet, RJ45 Connectors, Cat5e or better
LAN Protocols	Power over Ethernet (PoE, 802.3af) Network Access Control (IEEE8022.1x), HTTP, HTTPS, SIP2.0
Programming	Non- Volatile flash memory Programming and Configuration through Web GUI
Management And Operation	DHCP and Static IP, Remote authentic software upgrade, centralized monitoring
Echo/noise Cancellation Code	G.167/G.168
Amplifier Output	Built-in 25 Watt RMS for External Speaker
Sound Output	115 dB @ 1W, 1Mtr
Audio Codes	G.711, G.722, G.729
Speed Dialing Keypad	Super Strong Function is available for dialing 3 groups of numbers stored in the memory
Housing	Pressure die-cast robust aluminium body
Unit Size	335 x 353 x 125 mm
Weight	11 Kg
Environmental Conditions	Ambient temperature: -20℃ to 65℃, Relative humidity:10%~95% Atmospheric pressure: 86~106Kpa Circumstance noise: less than 60dB(A) Degree of protection: IP67
